NEXCOM Fanless Embedded Computer | NDiS V1100-i3-AIC

NEXCOM Fanless Embedded Computer | NDiS V1100-i3-AIC

Power your future with the 11th Gen Intel® Core™ edge computing solution

Merchandise number：10W00110009X0

Discounted price:US$
Sale US$
MSRP US$
Use bonus pointspt.

Description：

Tiger Lake Power :
Experience the latest in computing performance with the 11th Gen Intel® Core™ processor, delivering exceptional speed and efficiency.
Dual-Channel DDR4 Memory :
Accelerate your applications with up to 64GB of high-speed DDR4 memory.
Versatile Display Options :
Connect up to four 4K displays simultaneously for stunning visuals.
Robust Connectivity :
Benefit from dual LAN ports and three USB 3.0 ports for seamless connectivity.
Expandability :
Customize your system with an onboard M.2 2280 slot for high-speed storage and an additional mini-PCIe slot for wireless connectivity options.
Quiet and Reliable :
Enjoy fanless operation for silent and reliable performance.

Download file

Spec.

CPU Support
- Onboard 11th Gen Intel® Core™ i3-1115G4E processor, dual core, 2.2 GHz, 6M cache
Main Memory
- 2 x DDR4 8GB 2666 Industrial SO-DIMM
Display Option
- 4 x HDMI, support 4096 x 2160@60Hz
Front I/O Interface Status LEDs
- 1 x Power button with LED
- 1 x HDD LED
Front I/O Interface
- 2 x COM Port
  - COM1: RS232/422/485
  - COM2: RS232
  - 1 x Mic in
  - 1 x Line Out
  - 4 x Antenna holes
Rear I/O Interface
- 1 x 4-pin DC Jack, 12V
- 4 x HDMI
- 2 x RJ45 Intel® Gigabit LAN port
  - 1 x Intel® I219-LM GbE PHY
  - 1 x Intel® I225-V GbE LAN
- 3 x USB 3.2
- 1 x USB 2.0
- 1 x Antenna holeStorage Device
- 128GB M.2 2280 PCIe x 4 SSD Key M
Storage Device
- 128GB M.2 2280 PCIe x 4 SSD Key M
Expansion Slot
- 1 x M.2 3052 Key B, support optional 5G modules
- 1 x mini-PCIe, support optional 4G/Wi-fi/Bluetooth modules
Power Requirement
- 1 x External 96W AC/DC power adapter
- Input: 100V AC to 240V AC
- Output: DC+12VDC
Dimensions
- 190mm (W) x 165mm (D) x 51.1mm (H)
Construction
- Aluminum and metal chassis with fanless design
Environment
- Operating temperature: 0°C to 45°C
- Storage temperature: -20°C to 80°C
- Humidity: 10 to 90% (non-condensing)
Certification
- CE Approval
- FCC Class A
OS Support Lists
- Win10
- Linux
Weight Information
- 2kg

Own Brand, Own Factory Production: High-quality assurance and global fast shipping.
Ships Fast: Orders are processed and shipped within 2 business days.
2-Year Global Warranty: Limited hardware warranty from the shipment date.
30-Day Return Policy: Satisfaction guarantee window (terms apply).
Free Shipping: Complimentary shipping on eligible global orders.
Direct Support: For any usage issues after purchase, please feel free to contact us anytime.

NEXCOM Return & Warranty Policy

1. Return Window (30 Days)

Customers may request a return or exchange within 30 days. The period is calculated from the shipment date (as shown on the invoice) to the date the return request is formally submitted.

* Please note: A "Return" (for refund) is distinct from our "2-Year Hardware Warranty" (for repair).

2. 2-Year Limited Warranty

We provide a 2-year warranty on all Industrial PC hardware, starting from the shipment date. This covers technical defects in materials and workmanship. During this period, NEXCOM offers repair or replacement services according to the RMA evaluation.

3. Return Conditions

Items must be in original, unused condition with all original packaging, manuals, and accessories.
Customized Orders: IPCs with specific custom configurations (e.g., custom RAM/SSD/OS) are Non-Returnable unless a hardware defect is confirmed.
Electronic components must be returned in their original anti-static packaging.

4. Shipping & Destination

All returns must be shipped back to our headquarters in Taiwan:

Return Address:
NEXCOM International Co., Ltd.
9F, No.920, Zhongzheng Rd., Zhonghe Dist.,
New Taipei City, Taiwan 235015

Scenario	Cost Responsibility
Defective Items (DOA)	Seller covers return shipping.
Non-Defective Returns	Buyer covers shipping and duties. Restocking fees will be quoted based on actual inspection of the returned unit.

5. RMA Procedure

To initiate a return, please email us at ecommerce@nexcom.com.tw to obtain an RMA number.

* Shipments without an RMA number clearly marked on the outer box will be refused and returned at the sender's expense.

Contact Us: ecommerce@nexcom.com.tw
NEXCOM International Co., Ltd. | Industrial Computing Solutions

NEXCOM NDiS V1100-i3-AIC Datasheet
- NEXCOM AIoT Mart Customer Service Email: ecommerce@nexcom.com.tw
Access NEXCOM Industrial Solutions on Our Official Online Channels:

Specifications
CPU Support

Onboard 11th Gen Intel® Core™ i3-1115G4E processor, dual core, 2.2 GHz, 6M cache
Main Memory

2 x DDR4 8GB 2666 Industrial SO-DIMM
Display Option

4 x HDMI, support 4096 x 2160@60Hz
Front I/O Interface Status LEDs

1 x Power button with LED

1 x HDD LED
Front I/O Interface

2 x COM Port
- COM1: RS232/422/485
- COM2: RS232
- 1 x Mic in
- 1 x Line Out
- 4 x Antenna holes
Rear I/O Interface

1 x 4-pin DC Jack, 12V

4 x HDMI

2 x RJ45 Intel® Gigabit LAN port
- 1 x Intel® I219-LM GbE PHY
- 1 x Intel® I225-V GbE LAN

3 x USB 3.2

1 x USB 2.0

1 x Antenna holeStorage Device

128GB M.2 2280 PCIe x 4 SSD Key M
Storage Device

128GB M.2 2280 PCIe x 4 SSD Key M
Expansion Slot

1 x M.2 3052 Key B, support optional 5G modules

1 x mini-PCIe, support optional 4G/Wi-fi/Bluetooth modules
Power Requirement

1 x External 96W AC/DC power adapter

Input: 100V AC to 240V AC

Output: DC+12VDC
Dimensions

190mm (W) x 165mm (D) x 51.1mm (H)
Construction

Aluminum and metal chassis with fanless design
Environment

Operating temperature: 0°C to 45°C

Storage temperature: -20°C to 80°C

Humidity: 10 to 90% (non-condensing)
Certification

CE Approval

FCC Class A
OS Support Lists

Win10

Linux
Weight Information

2kg

After-sales service

Own Brand, Own Factory Production: High-quality assurance and global fast shipping.
Ships Fast: Orders are processed and shipped within 2 business days.
2-Year Global Warranty: Limited hardware warranty from the shipment date.
30-Day Return Policy: Satisfaction guarantee window (terms apply).
Free Shipping: Complimentary shipping on eligible global orders.
Direct Support: For any usage issues after purchase, please feel free to contact us anytime.

NEXCOM Return & Warranty Policy

1. Return Window (30 Days)

Customers may request a return or exchange within 30 days. The period is calculated from the shipment date (as shown on the invoice) to the date the return request is formally submitted.

* Please note: A "Return" (for refund) is distinct from our "2-Year Hardware Warranty" (for repair).

2. 2-Year Limited Warranty

3. Return Conditions

Items must be in original, unused condition with all original packaging, manuals, and accessories.
Customized Orders: IPCs with specific custom configurations (e.g., custom RAM/SSD/OS) are Non-Returnable unless a hardware defect is confirmed.
Electronic components must be returned in their original anti-static packaging.

4. Shipping & Destination

All returns must be shipped back to our headquarters in Taiwan:

Return Address:
NEXCOM International Co., Ltd.
9F, No.920, Zhongzheng Rd., Zhonghe Dist.,
New Taipei City, Taiwan 235015

Scenario	Cost Responsibility
Defective Items (DOA)	Seller covers return shipping.
Non-Defective Returns	Buyer covers shipping and duties. Restocking fees will be quoted based on actual inspection of the returned unit.

5. RMA Procedure

To initiate a return, please email us at ecommerce@nexcom.com.tw to obtain an RMA number.

* Shipments without an RMA number clearly marked on the outer box will be refused and returned at the sender's expense.

Contact Us: ecommerce@nexcom.com.tw
NEXCOM International Co., Ltd. | Industrial Computing Solutions

Download

NEXCOM NDiS V1100-i3-AIC Datasheet
Contact Us
- NEXCOM AIoT Mart Customer Service Email: ecommerce@nexcom.com.tw
Online Shopping

Access NEXCOM Industrial Solutions on Our Official Online Channels:

NEXCOM NDiS V1100-i3-AIC Industrial PC

Powering AI-Driven Elderly Care

The NEXCOM NDiS V1100 is a powerful edge AI computer designed to enhance elderly care and improve the quality of life for seniors. Leveraging the latest Intel® Core™ processor and Intel® Iris® Xe graphics, this compact and efficient device delivers exceptional performance and AI capabilities.

Ideal for :

Digital Signage:
Create eye-catching digital displays with multiple 4K outputs.
Industrial Automation:
Control and monitor industrial processes with precision.
IoT Edge Computing:
Collect and process data from IoT devices.
AI and Machine Learning:
Accelerate your AI and machine learning workloads.
Benefits:

Benefits :

Unmatched Performance:
Delivering exceptional performance for the most demanding applications.
Versatility:
Adapts to a wide range of use cases and industries.
Reliability:
Built to withstand harsh environments and deliver continuous operation.
Scalability:
Easily expand your system as your needs grow.
Highlight the benefits of the 11th Gen Intel® Core™ processor:
Emphasize performance improvements, energy efficiency, and new features.
Showcase the system's capabilities for AI and machine learning:
Demonstrate how it can accelerate deep learning models and other AI workloads.
Emphasize the importance of multiple display outputs:
Explain how this can be used for digital signage, control rooms, and other visual applications.
Focus on the system's reliability and durability:
Highlight the benefits of fanless operation and the use of high-quality components.
Create a compelling call to action:
Encourage potential customers to contact you for a demonstration or to learn more about the product.

Experience the Future of Embedded Computing

This cutting-edge system is designed to meet the evolving needs of modern businesses. With its powerful performance, flexible connectivity, and compact design, it's the ideal choice for a wide range of applications.

Highlight the benefits of the 11th Gen Intel® Core™ processor:
Emphasize performance improvements, energy efficiency, and new features.
Showcase the system's capabilities for AI and machine learning:
Demonstrate how it can accelerate deep learning models and other AI workloads.
Emphasize the importance of multiple display outputs:
Explain how this can be used for digital signage, control rooms, and other visual applications.
Focus on the system's reliability and durability:
Highlight the benefits of fanless operation and the use of high-quality components.
Create a compelling call to action:
Encourage potential customers to contact you for a demonstration or to learn more about the product.

Applications for better elderly care

AI uses powerful computer hardware to “see” the environment through cameras and respond to real-world events. By leveraging the power of computerized automation, an edge AI computer system can function as monitoring systems, AIoT health monitors, smart home hubs, and provide AI facial detection.

- Patient monitoring systems track the safety of the elderly within a care facility. Cameras monitor patients in the care facility and analyze video data to detect patients wandering off, going to restricted areas, or even falling down. Staff no longer have to keep their eyes on the screens and are alerted if anything happens.

- AIoT health monitors keep a complete record of patient health. Connected wearables collect detailed information so medical personnel can detect ailments early, make better decisions, and more accurately assess patients’ health status.

- Smart home hubs for elderly care act as a central hub for home monitoring systems for home health care. By bringing all health data into a centralized location, these home hubs can simplify the monitoring of health information and allow access to professional care services remotely so a doctor can keep close checks on patient health without having to be physically on-site.

NEXCOM — Better elderly care through AI technology

The NEXCOM NEXCOM NDiS V1100 is a fanless edge AI computer that provides the processing power to enable AI applications that improve the lives of the elderly, and bolster the capacity of the healthcare system elderly care facilities.
