NEXCOM Industrial NAS | iNAS330 [EOL]

Uncompromising Performance in Extreme Conditions

Merchandise number：10IG0033000X0

Discounted price:US$
Sale US$
MSRP US$
Use bonus pointspt.

Description：

Our cutting-edge device delivers unmatched reliability and efficiency, even in the harshest environments.

Redundant Power and Data:
Dual Gigabit Ethernet ports with PoE+ ensure uninterrupted operation and data integrity.
Rock-Solid Reliability:
Built to withstand extreme vibrations, shocks, and wide temperature fluctuations, fully compliant with EN50155 and EN61373 standards.
Rugged Design:
IP54 rating protects against dust and water ingress.
Unmatched Durability:
Designed to operate flawlessly in temperatures ranging from -40°C to 70°C.
Maximize Uptime:
Redundant systems and rugged construction ensure continuous operation.
Protect Your Data:
Safeguard critical data from environmental hazards.
Versatile Applications:
Ideal for demanding applications in railways, industrial automation, and more.
Future-Proof:
Built to meet the rigorous requirements of today's and tomorrow's applications.

Download file

Spec.

Main Board
- Dual Cortex®-A9 CPU
Storage
- 3 x 2.5" SATA SSD socket, up to 1T each SSD
EthernetStorage
- 2 x Gigabit LAN ports for data redundancy (M12)
- 1 x Gigabit LAN port for management (M12)
Button
- Reset button: Reboot System/Reset to factory default
LEDs
- Power LED: power On/Off
- System LED: system status
- PoE/Temp LED: PoE/Temp status
- HDD LED: HDD1, HDD2,HDD3 (read/write/fail)
- LAN LED: 10/100/1000M x3 (link/activity)
Power Requirements
- Input: PoE (IEEE 802.3af), or PoE + (IEEE 802.3at)
- Power redundancy
HS Control
- Smart heating system
Physical Characteristics
- Fanless
- Housing: metal, IP 54 protection
Environmental Specification
- Operating temperature: -40°C ~ 70°C (-40°F ~ 158°F)
- Storage temperature: -40°C ~ 85°C (-40°F ~ 176°F)
- Humidity: 5% - 95%, non-condensing
Certifications
- FCC
- RoHS/WEEE
Accessories
- Wall mount kit x 1
- M12 cables x 3 (waterproof 8-pin male M12 to RJ45 gigabit Ethernet )
System Dimensions
- 246mm (w) x 194mm (D) x 60mm (H) (9.69" x 7.64" x 2.36")
Software Features
- OS: Atlas OS ™
  - Web-based GUI (based on HTML5 and CSS3)
  - Centralized navigation panel and Dual-desktop system:
  Navigation Panel: For system configurations, with some toolkits on the toolbar
  - Home: for applications operations
  - Dashboard: For widgets exhibition
- APPs
  - Storage Manager
  - RAID management (JBOD, RAID1, RAID 5)/Auto RAID rebuilding
  - Data Vault
  - Log Book
  - Software Center
- Widgets
  - System Guardian
  - Network Surveillance
- Configurations
  - Files and permissions
  - Network and connectivity
  - System and devices
- Toolkit
  - Profile: account management
  - Real-time notification
  - System information
  - Network status
Client O.S. support
- Windows 7+, Windows Server 2003 R2, 2008, 2008 R2 & 2012 or later
- Linux & UNIX
- Mac OS X 10.7 or later
Web Browsers Support
- Mozilla Firefox
- Mac Safari
- Google Chrome
- Opera
Protocol
- HTTP/H - SAMBA 2 (CIFS),Open SSL (TLS),FTP / FTPS
- HTTP 1.1 / HTTPS
- IPv4,Link Aggregation, DHCP,NTP,HTTP Authentication
- RESTful API

Own Brand, Own Factory Production: High-quality assurance and global fast shipping.
Ships Fast: Orders are processed and shipped within 2 business days.
Special EOL Offer: Limited availability for this discontinued model.
3-Month DOA Policy: Replacement or refund for defective units.
Free Shipping: Complimentary shipping on eligible global orders.
Direct Support: Professional technical assistance available (fees may apply after the DOA period).

NEXCOM Return & Warranty Policy (EOL Product)

1. Product Status

This is an End-of-Life (EOL) model. Please be advised that technical maintenance has been officially discontinued for this product.

2. Operating Requirements

Stable internet connectivity is required for operation. Please note that no further software or firmware updates or maintenance will be released for this model.

3. Warranty Policy

This product is covered by a Limited 3-month DOA (Dead on Arrival) return policy, starting from the shipment date. No further hardware warranty or repairs will be provided after the initial 3-month period. Any subsequent technical support requests will be handled as a paid service.

4. Shipping & Destination

All returns must be shipped back to our headquarters in Taiwan:

Return Address:
NEXCOM International Co., Ltd.
9F, No.920, Zhongzheng Rd., Zhonghe Dist.,
New Taipei City, Taiwan 235015

Scenario	Cost Responsibility
Defective Items (DOA within 3 months)	Seller covers return shipping.
Non-Defective Returns	Buyer covers shipping and duties. Restocking fees will be quoted based on inspection.

5. RMA Procedure

To initiate a return within the valid 3-month period, please email us at ecommerce@nexcom.com.tw to obtain an RMA number.

Contact Us: ecommerce@nexcom.com.tw
NEXCOM International Co., Ltd. | Industrial Computing Solutions

NEXCOM iNAS330 Datasheet
- NEXCOM AIoT Mart Customer Service Email: ecommerce@nexcom.com.tw
Access NEXCOM Industrial Solutions on Our Official Online Channels:

Specifications
Main Board

Dual Cortex®-A9 CPU
Storage

3 x 2.5" SATA SSD socket, up to 1T each SSD
EthernetStorage

2 x Gigabit LAN ports for data redundancy (M12)

1 x Gigabit LAN port for management (M12)
Button

Reset button: Reboot System/Reset to factory default
LEDs

Power LED: power On/Off

System LED: system status

PoE/Temp LED: PoE/Temp status

HDD LED: HDD1, HDD2,HDD3 (read/write/fail)

LAN LED: 10/100/1000M x3 (link/activity)
Power Requirements

Input: PoE (IEEE 802.3af), or PoE + (IEEE 802.3at)

Power redundancy
HS Control

Smart heating system
Physical Characteristics

Fanless

Housing: metal, IP 54 protection
Environmental Specification

Operating temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Storage temperature: -40°C ~ 85°C (-40°F ~ 176°F)

Humidity: 5% - 95%, non-condensing
Certifications

FCC

RoHS/WEEE
Accessories

Wall mount kit x 1

M12 cables x 3 (waterproof 8-pin male M12 to RJ45 gigabit Ethernet )
System Dimensions

246mm (w) x 194mm (D) x 60mm (H) (9.69" x 7.64" x 2.36")
Software Features

OS: Atlas OS ™
- Web-based GUI (based on HTML5 and CSS3)
- Centralized navigation panel and Dual-desktop system:
Navigation Panel: For system configurations, with some toolkits on the toolbar
- Home: for applications operations
- Dashboard: For widgets exhibition

APPs
- Storage Manager
- RAID management (JBOD, RAID1, RAID 5)/Auto RAID rebuilding
- Data Vault
- Log Book
- Software Center

Widgets
- System Guardian
- Network Surveillance

Configurations
- Files and permissions
- Network and connectivity
- System and devices

Toolkit
- Profile: account management
- Real-time notification
- System information
- Network status
Client O.S. support

Windows 7+, Windows Server 2003 R2, 2008, 2008 R2 & 2012 or later

Linux & UNIX

Mac OS X 10.7 or later
Web Browsers Support

Mozilla Firefox

Mac Safari

Google Chrome

Opera
Protocol

HTTP/H - SAMBA 2 (CIFS),Open SSL (TLS),FTP / FTPS

HTTP 1.1 / HTTPS

IPv4,Link Aggregation, DHCP,NTP,HTTP Authentication

RESTful API

After-sales service

Own Brand, Own Factory Production: High-quality assurance and global fast shipping.
Ships Fast: Orders are processed and shipped within 2 business days.
Special EOL Offer: Limited availability for this discontinued model.
3-Month DOA Policy: Replacement or refund for defective units.
Free Shipping: Complimentary shipping on eligible global orders.
Direct Support: Professional technical assistance available (fees may apply after the DOA period).

NEXCOM Return & Warranty Policy (EOL Product)

1. Product Status

This is an End-of-Life (EOL) model. Please be advised that technical maintenance has been officially discontinued for this product.

2. Operating Requirements

Stable internet connectivity is required for operation. Please note that no further software or firmware updates or maintenance will be released for this model.

3. Warranty Policy

4. Shipping & Destination

All returns must be shipped back to our headquarters in Taiwan:

Return Address:
NEXCOM International Co., Ltd.
9F, No.920, Zhongzheng Rd., Zhonghe Dist.,
New Taipei City, Taiwan 235015

Scenario	Cost Responsibility
Defective Items (DOA within 3 months)	Seller covers return shipping.
Non-Defective Returns	Buyer covers shipping and duties. Restocking fees will be quoted based on inspection.

5. RMA Procedure

To initiate a return within the valid 3-month period, please email us at ecommerce@nexcom.com.tw to obtain an RMA number.

Contact Us: ecommerce@nexcom.com.tw
NEXCOM International Co., Ltd. | Industrial Computing Solutions

Download

NEXCOM iNAS330 Datasheet
Contact Us
- NEXCOM AIoT Mart Customer Service Email: ecommerce@nexcom.com.tw
Online Shopping

Access NEXCOM Industrial Solutions on Our Official Online Channels:

NEXCOM NEXCOM iNAS 330 Industrial PC

Stable Storage and Remote Access in Harsh Environments

The NEXCOM iNAS330 is a rugged, high-performance network-attached storage (NAS) solution built to excel in the toughest environments. With advanced SSD storage technology, it ensures reliable data capture and secure storage in industries like oil exploration, transportation, and industrial automation—delivering unmatched durability where it's needed most.

Key Features

Rugged design:
Operates in harsh environments with wide temperature range and IP54 protection.
High performance:
Powerful processor, SSD storage, and fast network connections.
Data protection:
RAID 5 support, data encryption, and multiple backup options.
Remote access:
Web-based management, SNMP, RESTful API, and email notifications.
Power efficiency:
PoE/PoE+ support and dual PoE+ interface.
Atlas OS:
User-friendly interface, real-time monitoring, and management tools.
Applications:
Suitable for oil exploration, transportation, industrial automation, and other demanding environments.

A Perfect Fit for the Modern NAS Market

The NEXCOM iNAS 330 is a perfect fit for the modern NAS market, offering unmatched durability and performance in even the harshest environments. Designed to meet the demands of industries like transportation, oil exploration, and industrial automation, it ensures reliable data storage and seamless access — empowering businesses to thrive in challenging conditions.

Challenge the Standards

The NEXCOM iNAS 330 is set to disrupt the NAS market with its unmatched durability, performance, and adaptability. Designed for industries that demand more from their storage solutions, it offers key advantages that competitors struggle to match:

Built for Harsh Environments:
Unlike traditional NAS systems, the iNAS 330 thrives in extreme temperatures, high humidity, and dusty conditions, making it ideal for industrial and outdoor applications.
Power Where Others Fail:
With dual PoE+ ports and power redundancy, it operates in locations without traditional power sources, ensuring reliability in remote areas.
Seamless Management:
Atlas OS™ simplifies storage and network management with real-time monitoring, RAID protection, and remote access—outperforming systems with complex setups.
Future-Ready Design:
Its rugged build, scalable software, and robust features make it a long-term solution for evolving industry needs.

Why Choose NEXCOM iNAS 330?

Durable Design:
Operates in extreme temperatures (-40°C to 70°C with SSDs) with an IP54-rated, fanless, dust- and water-resistant chassis.
Reliable Data Protection:
Supports RAID 5 for fault tolerance, with advanced damage detection and recovery.
Easy Setup and Power:
Dual PoE+ ports for power and data, plus power redundancy for stability.
Atlas OS™:
User-friendly web interface for real-time monitoring, RAID management, and remote access from any device.
High Performance:
Powered by a Marvell™ dual-core processor, supporting three 2.5” drives and efficient data sharing via FTP and SMB/CIFS.
